Interface for local matrix classes. More...

#include <dune/fem/operator/common/localmatrix.hh>

Inheritance diagram for Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >:

Public Types
typedef LocalMatrixTraits	Traits
	type of traits class

typedef ThisType	LocalMatrixInterfaceType
	type of this interface

typedef Traits::LocalMatrixType	LocalMatrixType
	type of local matrix implementation

typedef Traits::RangeFieldType	RangeFieldType
	type of range field

typedef Traits::DomainSpaceType	DomainSpaceType
	type of domain discrete function space

typedef Traits::RangeSpaceType	RangeSpaceType
	type of range discrete function space

typedef DomainSpaceType::BasisFunctionSetType	DomainBasisFunctionSetType
	type of base function sets within domain function space

typedef RangeSpaceType::BasisFunctionSetType	RangeBasisFunctionSetType
	type of base function sets within range function space

typedef DomainSpaceType::EntityType	DomainEntityType

typedef RangeSpaceType::EntityType	RangeEntityType

typedef Traits::LittleBlockType	LittleBlockType

typedef MatrixColumnObject< Traits >	MatrixColumnType

Public Member Functions
void	init (const DomainEntityType &domainEntity, const RangeEntityType &rangeEntity)
	initialize the local matrix to entities

void	bind (const DomainEntityType &domainEntity, const RangeEntityType &rangeEntity)
	initialize the local matrix to entities

void	unbind ()
	clear local matrix from entities

void	add (const int localRow, const int localCol, const RangeFieldType &value)
	add value to matrix entry (row,col) where row and col are local row and local column

void	set (const int localRow, const int localCol, const RangeFieldType &value)
	set value of matrix entry (row,col) where row and col are local row and local column

void	clearRow (const int localRow)
	set row to zero values

void	clearCol (const int localCol)
	ser column entries to zero

template<class DomainLocalFunctionType , class RangeLocalFunctionType >
void	multiplyAdd (const DomainLocalFunctionType &lhs, RangeLocalFunctionType &rhs) const
	multiply left hand side with local matrix and add to right hand side rhs += Matrix * lhs

const RangeFieldType	get (const int localRow, const int localCol) const
	get value of matrix entry (row,col) where row and col are local row and local column

void	scale (const RangeFieldType &scalar)
	scale matrix with scalar value

void	clear ()
	set all entries of local matrix to zero

void	resort ()
	resort ordering in global matrix (if possible)

int	rows () const
	get number of rows within the matrix

int	columns () const
	get number of columns within the matrix

const DomainSpaceType &	domainSpace () const
	access to the domain space

const RangeSpaceType &	rangeSpace () const
	access to the range space

const DomainBasisFunctionSetType &	domainBasisFunctionSet () const
	access to the base function set within the domain space

const RangeBasisFunctionSetType &	rangeBasisFunctionSet () const
	access to the base function set within the range space

const DomainEntityType &	domainEntity () const

const RangeEntityType &	rangeEntity () const

MatrixColumnType	column (const unsigned int col)
	return column object for local matrix which contains axpy methods for convenience

void	finalize ()
	finalize local matrix setup and possibly add values to real matrix

Protected Member Functions
	LocalMatrixInterface ()
	constructor

const Implementation &	asImp () const

Implementation &	asImp ()

Static Protected Member Functions
static const Implementation &	asImp (const ThisType &other)

static Implementation &	asImp (ThisType &other)

static const LocalMatrixTraits::LocalMatrixType &	asImp (const ThisType &other)

static LocalMatrixTraits::LocalMatrixType &	asImp (ThisType &other)

Detailed Description

template<class LocalMatrixTraits>
class Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >

Interface for local matrix classes.

Member Typedef Documentation

◆ DomainBasisFunctionSetType

template<class LocalMatrixTraits >

typedef DomainSpaceType::BasisFunctionSetType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::DomainBasisFunctionSetType

type of base function sets within domain function space

◆ DomainEntityType

template<class LocalMatrixTraits >

typedef DomainSpaceType::EntityType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::DomainEntityType

◆ DomainSpaceType

template<class LocalMatrixTraits >

typedef Traits::DomainSpaceType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::DomainSpaceType

type of domain discrete function space

◆ LittleBlockType

template<class LocalMatrixTraits >

typedef Traits::LittleBlockType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LittleBlockType

type of block (i.e. FieldMatrix for BlockMatrices

◆ LocalMatrixInterfaceType

template<class LocalMatrixTraits >

typedef ThisType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LocalMatrixInterfaceType

type of this interface

◆ LocalMatrixType

template<class LocalMatrixTraits >

typedef Traits::LocalMatrixType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LocalMatrixType

type of local matrix implementation

◆ MatrixColumnType

template<class LocalMatrixTraits >

typedef MatrixColumnObject< Traits > Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::MatrixColumnType

◆ RangeBasisFunctionSetType

template<class LocalMatrixTraits >

typedef RangeSpaceType::BasisFunctionSetType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::RangeBasisFunctionSetType

type of base function sets within range function space

◆ RangeEntityType

template<class LocalMatrixTraits >

typedef RangeSpaceType::EntityType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::RangeEntityType

◆ RangeFieldType

template<class LocalMatrixTraits >

typedef Traits::RangeFieldType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::RangeFieldType

type of range field

◆ RangeSpaceType

template<class LocalMatrixTraits >

typedef Traits::RangeSpaceType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::RangeSpaceType

type of range discrete function space

◆ Traits

template<class LocalMatrixTraits >

typedef LocalMatrixTraits Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::Traits

type of traits class

Constructor & Destructor Documentation

◆ LocalMatrixInterface()

template<class LocalMatrixTraits >

Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LocalMatrixInterface ( )

inlineprotected

constructor

Member Function Documentation

◆ add()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::add	(	const int	localRow,
		const int	localCol,
		const RangeFieldType &	value
	)

inline

add value to matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column
[in]	value	value to add

◆ asImp() [1/6]

template<class LocalMatrixTraits >

Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( )

inlineprotected

◆ asImp() [2/6]

template<class LocalMatrixTraits >

const Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( ) const

inlineprotected

◆ asImp() [3/6]

static const LocalMatrixTraits::LocalMatrixType & Dune::Fem::BartonNackmanInterface< LocalMatrixInterface< LocalMatrixTraits > , LocalMatrixTraits::LocalMatrixType >::asImp ( const ThisType & other )

inlinestaticprotectedinherited

◆ asImp() [4/6]

template<class LocalMatrixTraits >

static const Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( const ThisType & other )

inlinestaticprotected

◆ asImp() [5/6]

static LocalMatrixTraits::LocalMatrixType & Dune::Fem::BartonNackmanInterface< LocalMatrixInterface< LocalMatrixTraits > , LocalMatrixTraits::LocalMatrixType >::asImp ( ThisType & other )

inlinestaticprotectedinherited

◆ asImp() [6/6]

template<class LocalMatrixTraits >

static Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( ThisType & other )

inlinestaticprotected

◆ bind()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::bind	(	const DomainEntityType &	domainEntity,
		const RangeEntityType &	rangeEntity
	)

inline

initialize the local matrix to entities

Parameters

[in]	domainEntity	entity within grid of domain space,
[in]	rangeEntity	entity within grid of range space

◆ clear()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::clear ( )

inline

set all entries of local matrix to zero

◆ clearCol()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::clearCol ( const int localCol )

inline

ser column entries to zero

Parameters

[in] localCol local column that is set to zero

◆ clearRow()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::clearRow ( const int localRow )

inline

set row to zero values

Parameters

[in] localRow local row that is set to zero

◆ column()

template<class LocalMatrixTraits >

MatrixColumnType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::column ( const unsigned int col )

inline

return column object for local matrix which contains axpy methods for convenience

Parameters

col	local column number

Returns: object of type MatrixColumnObject

◆ columns()

template<class LocalMatrixTraits >

int Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::columns ( ) const

inline

get number of columns within the matrix

◆ domainBasisFunctionSet()

template<class LocalMatrixTraits >

const DomainBasisFunctionSetType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::domainBasisFunctionSet ( ) const

inline

access to the base function set within the domain space

◆ domainEntity()

template<class LocalMatrixTraits >

const DomainEntityType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::domainEntity ( ) const

inline

◆ domainSpace()

template<class LocalMatrixTraits >

const DomainSpaceType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::domainSpace ( ) const

inline

access to the domain space

◆ finalize()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::finalize ( )

inline

finalize local matrix setup and possibly add values to real matrix

◆ get()

template<class LocalMatrixTraits >

const RangeFieldType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::get	(	const int	localRow,
		const int	localCol
	)		const

inline

get value of matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column

Returns: value of matrix entry

◆ init()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::init	(	const DomainEntityType &	domainEntity,
		const RangeEntityType &	rangeEntity
	)

inline

initialize the local matrix to entities

Parameters

[in]	domainEntity	entity within grid of domain space,
[in]	rangeEntity	entity within grid of range space

◆ multiplyAdd()

template<class LocalMatrixTraits >

template<class DomainLocalFunctionType , class RangeLocalFunctionType >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::multiplyAdd	(	const DomainLocalFunctionType &	lhs,
		RangeLocalFunctionType &	rhs
	)		const

inline

multiply left hand side with local matrix and add to right hand side rhs += Matrix * lhs

Parameters

[in]	lhs	left hand side
[out]	rhs	right hand side

◆ rangeBasisFunctionSet()

template<class LocalMatrixTraits >

const RangeBasisFunctionSetType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::rangeBasisFunctionSet ( ) const

inline

access to the base function set within the range space

◆ rangeEntity()

template<class LocalMatrixTraits >

const RangeEntityType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::rangeEntity ( ) const

inline

◆ rangeSpace()

template<class LocalMatrixTraits >

const RangeSpaceType & Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::rangeSpace ( ) const

inline

access to the range space

◆ resort()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::resort ( )

inline

resort ordering in global matrix (if possible)

◆ rows()

template<class LocalMatrixTraits >

int Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::rows ( ) const

inline

get number of rows within the matrix

◆ scale()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::scale ( const RangeFieldType & scalar )

inline

scale matrix with scalar value

Parameters

[in] scalar scalar value that scales the matrix

◆ set()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::set	(	const int	localRow,
		const int	localCol,
		const RangeFieldType &	value
	)

inline

set value of matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column
[in]	value	value to set

◆ unbind()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::unbind ( )

inline

clear local matrix from entities

The documentation for this class was generated from the following file:

localmatrix.hh

Public Types

Public Member Functions

Protected Member Functions

Static Protected Member Functions

Detailed Description

Member Typedef Documentation

◆ DomainBasisFunctionSetType

◆ DomainEntityType

◆ DomainSpaceType

◆ LittleBlockType

◆ LocalMatrixInterfaceType

◆ LocalMatrixType

◆ MatrixColumnType

◆ RangeBasisFunctionSetType

◆ RangeEntityType

◆ RangeFieldType

◆ RangeSpaceType

◆ Traits

Constructor & Destructor Documentation

◆ LocalMatrixInterface()

Member Function Documentation

◆ add()

◆ asImp() [1/6]

◆ asImp() [2/6]

◆ asImp() [3/6]

◆ asImp() [4/6]

◆ asImp() [5/6]

◆ asImp() [6/6]

◆ bind()

◆ clear()

◆ clearCol()

◆ clearRow()

◆ column()

◆ columns()

◆ domainBasisFunctionSet()

◆ domainEntity()

◆ domainSpace()

◆ finalize()

◆ get()

◆ init()

◆ multiplyAdd()

◆ rangeBasisFunctionSet()

◆ rangeEntity()

◆ rangeSpace()

◆ resort()

◆ rows()

◆ scale()

◆ set()

◆ unbind()
