Dune::Fem::LocalMatrixDefault< LocalMatrixTraits > Class Template Reference

Default implementation for local matrix classes. More...

#include <dune/fem/operator/common/localmatrix.hh>

Inheritance diagram for Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >:

Public Types
typedef LocalMatrixTraits	Traits
typedef BaseType::DomainSpaceType	DomainSpaceType
typedef BaseType::RangeSpaceType	RangeSpaceType
typedef BaseType::DomainBasisFunctionSetType	DomainBasisFunctionSetType
typedef BaseType::RangeBasisFunctionSetType	RangeBasisFunctionSetType
typedef BaseType::DomainEntityType	DomainEntityType
typedef BaseType::RangeEntityType	RangeEntityType
typedef ThisType	LocalMatrixInterfaceType
	type of this interface
typedef Traits::LocalMatrixType	LocalMatrixType
	type of local matrix implementation
typedef Traits::RangeFieldType	RangeFieldType
	type of range field
typedef Traits::LittleBlockType	LittleBlockType
typedef MatrixColumnObject< Traits >	MatrixColumnType

Public Member Functions
void	init (const DomainEntityType &domainEntity, const RangeEntityType &rangeEntity)
	initialize the local matrix to entities
void	bind (const DomainEntityType &domainEntity, const RangeEntityType &rangeEntity)
	initialize the local matrix to entities
void	unbind ()
	clear local matrix from entities
void	resort ()
	resort ordering in global matrix (if possible)
void	finalize ()
	finalize local matrix setup and possibly add values to real matrix
int	rows () const
	get number of rows within the matrix
int	columns () const
	get number of columns within the matrix
const DomainSpaceType &	domainSpace () const
	access to the domain space
const RangeSpaceType &	rangeSpace () const
	access to the range space
const DomainBasisFunctionSetType &	domainBasisFunctionSet () const
	access to the base function set within the domain space
const RangeBasisFunctionSetType &	rangeBasisFunctionSet () const
	access to the base function set within the range space
const DomainEntityType &	domainEntity () const
const RangeEntityType &	rangeEntity () const
template<class DomainLocalFunctionType , class RangeLocalFunctionType >
void	multiplyAdd (const DomainLocalFunctionType &lhs, RangeLocalFunctionType &rhs) const
	multiply left hand side with local matrix and add to right hand side rhs += Matrix * lhs
void	clearRow (const int localRow)
	set row to zero values
void	clearCol (const int localCol)
	ser column entries to zero
void	add (const int localRow, const int localCol, const RangeFieldType &value)
	add value to matrix entry (row,col) where row and col are local row and local column
void	set (const int localRow, const int localCol, const RangeFieldType &value)
	set value of matrix entry (row,col) where row and col are local row and local column
const RangeFieldType	get (const int localRow, const int localCol) const
	get value of matrix entry (row,col) where row and col are local row and local column
void	scale (const RangeFieldType &scalar)
	scale matrix with scalar value
void	clear ()
	set all entries of local matrix to zero
MatrixColumnType	column (const unsigned int col)
	return column object for local matrix which contains axpy methods for convenience

Protected Member Functions
	LocalMatrixDefault (const DomainSpaceType &domainSpace, const RangeSpaceType &rangeSpace)
template<class DomainEntityType , class RangeEntityType >
	LocalMatrixDefault (const DomainSpaceType &domainSpace, const RangeSpaceType &rangeSpace, const DomainEntityType &domainEntity, const RangeEntityType &rangeEntity)
	LocalMatrixDefault (const LocalMatrixDefault &org)
const Implementation &	asImp () const
Implementation &	asImp ()

Static Protected Member Functions
static const Implementation &	asImp (const ThisType &other)
static Implementation &	asImp (ThisType &other)
static const LocalMatrixTraits::LocalMatrixType &	asImp (const ThisType &other)
static LocalMatrixTraits::LocalMatrixType &	asImp (ThisType &other)

Protected Attributes
const DomainSpaceType &	domainSpace_
const RangeSpaceType &	rangeSpace_
DomainBasisFunctionSetType	domainBaseSet_
RangeBasisFunctionSetType	rangeBaseSet_
std::optional< DomainEntityType >	domainEntity_
std::optional< RangeEntityType >	rangeEntity_

Detailed Description

template<class LocalMatrixTraits>
class Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >

Default implementation for local matrix classes.

Member Typedef Documentation

DomainBasisFunctionSetType

template<class LocalMatrixTraits >

typedef BaseType::DomainBasisFunctionSetType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::DomainBasisFunctionSetType

DomainEntityType

template<class LocalMatrixTraits >

typedef BaseType::DomainEntityType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::DomainEntityType

DomainSpaceType

template<class LocalMatrixTraits >

typedef BaseType::DomainSpaceType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::DomainSpaceType

LittleBlockType

template<class LocalMatrixTraits >

typedef Traits::LittleBlockType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LittleBlockType

inherited

type of block (i.e. FieldMatrix for BlockMatrices

LocalMatrixInterfaceType

template<class LocalMatrixTraits >

typedef ThisType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LocalMatrixInterfaceType

inherited

type of this interface

LocalMatrixType

template<class LocalMatrixTraits >

typedef Traits::LocalMatrixType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::LocalMatrixType

inherited

type of local matrix implementation

MatrixColumnType

template<class LocalMatrixTraits >

typedef MatrixColumnObject< Traits > Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::MatrixColumnType

inherited

RangeBasisFunctionSetType

template<class LocalMatrixTraits >

typedef BaseType::RangeBasisFunctionSetType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::RangeBasisFunctionSetType

RangeEntityType

template<class LocalMatrixTraits >

typedef BaseType::RangeEntityType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::RangeEntityType

RangeFieldType

template<class LocalMatrixTraits >

typedef Traits::RangeFieldType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::RangeFieldType

inherited

type of range field

RangeSpaceType

template<class LocalMatrixTraits >

typedef BaseType::RangeSpaceType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::RangeSpaceType

Traits

template<class LocalMatrixTraits >

typedef LocalMatrixTraits Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::Traits

Constructor & Destructor Documentation

LocalMatrixDefault() [1/3]

template<class LocalMatrixTraits >

Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::LocalMatrixDefault ( const DomainSpaceType &  domainSpace, const RangeSpaceType &  rangeSpace  )

inlineprotected

LocalMatrixDefault() [2/3]

template<class LocalMatrixTraits >

template<class DomainEntityType , class RangeEntityType >

Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::LocalMatrixDefault ( const DomainSpaceType &  domainSpace, const RangeSpaceType &  rangeSpace, const DomainEntityType &  domainEntity, const RangeEntityType &  rangeEntity  )

inlineprotected

LocalMatrixDefault() [3/3]

template<class LocalMatrixTraits >

Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::LocalMatrixDefault ( const LocalMatrixDefault< LocalMatrixTraits > &  org )

inlineprotected

Member Function Documentation

add()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::add ( const int  localRow, const int  localCol, const RangeFieldType &  value  )

inlineinherited

add value to matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column
[in]	value	value to add

asImp() [1/6]

template<class LocalMatrixTraits >

Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( )

inlineprotectedinherited

asImp() [2/6]

template<class LocalMatrixTraits >

const Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( ) const

inlineprotectedinherited

asImp() [3/6]

static const LocalMatrixTraits::LocalMatrixType & Dune::Fem::BartonNackmanInterface< LocalMatrixInterface< LocalMatrixTraits > , LocalMatrixTraits::LocalMatrixType >::asImp ( const ThisType &  other )

inlinestaticprotectedinherited

asImp() [4/6]

template<class LocalMatrixTraits >

static const Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( const ThisType &  other )

inlinestaticprotectedinherited

asImp() [5/6]

static LocalMatrixTraits::LocalMatrixType & Dune::Fem::BartonNackmanInterface< LocalMatrixInterface< LocalMatrixTraits > , LocalMatrixTraits::LocalMatrixType >::asImp ( ThisType &  other )

inlinestaticprotectedinherited

asImp() [6/6]

template<class LocalMatrixTraits >

static Implementation & Dune::Fem::BartonNackmanInterface< Interface, Implementation >::asImp ( ThisType &  other )

inlinestaticprotectedinherited

bind()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::bind ( const DomainEntityType &  domainEntity, const RangeEntityType &  rangeEntity  )

inline

initialize the local matrix to entities

Parameters

[in]	domainEntity	entity within grid of domain space,
[in]	rangeEntity	entity within grid of range space

clear()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::clear ( )

inlineinherited

set all entries of local matrix to zero

clearCol()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::clearCol ( const int  localCol )

inline

ser column entries to zero

Parameters

[in]

localCol

local column that is set to zero

clearRow()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::clearRow ( const int  localRow )

inline

set row to zero values

Parameters

[in]

localRow

local row that is set to zero

column()

template<class LocalMatrixTraits >

MatrixColumnType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::column ( const unsigned int  col )

inlineinherited

return column object for local matrix which contains axpy methods for convenience

Parameters

col	local column number

Returns

object of type MatrixColumnObject

columns()

template<class LocalMatrixTraits >

int Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::columns ( ) const

inline

get number of columns within the matrix

domainBasisFunctionSet()

template<class LocalMatrixTraits >

const DomainBasisFunctionSetType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainBasisFunctionSet ( ) const

inline

access to the base function set within the domain space

domainEntity()

template<class LocalMatrixTraits >

const DomainEntityType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainEntity ( ) const

inline

domainSpace()

template<class LocalMatrixTraits >

const DomainSpaceType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainSpace ( ) const

inline

access to the domain space

finalize()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::finalize ( )

inline

finalize local matrix setup and possibly add values to real matrix

get()

template<class LocalMatrixTraits >

const RangeFieldType Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::get ( const int  localRow, const int  localCol  ) const

inlineinherited

get value of matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column

Returns

value of matrix entry

init()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::init ( const DomainEntityType &  domainEntity, const RangeEntityType &  rangeEntity  )

inline

initialize the local matrix to entities

Parameters

[in]	domainEntity	entity within grid of domain space,
[in]	rangeEntity	entity within grid of range space

multiplyAdd()

template<class LocalMatrixTraits >

template<class DomainLocalFunctionType , class RangeLocalFunctionType >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::multiplyAdd ( const DomainLocalFunctionType &  lhs, RangeLocalFunctionType &  rhs  ) const

inline

multiply left hand side with local matrix and add to right hand side rhs += Matrix * lhs

Parameters

[in]	lhs	left hand side
[out]	rhs	right hand side

rangeBasisFunctionSet()

template<class LocalMatrixTraits >

const RangeBasisFunctionSetType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeBasisFunctionSet ( ) const

inline

access to the base function set within the range space

rangeEntity()

template<class LocalMatrixTraits >

const RangeEntityType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeEntity ( ) const

inline

rangeSpace()

template<class LocalMatrixTraits >

const RangeSpaceType & Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeSpace ( ) const

inline

access to the range space

resort()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::resort ( )

inline

resort ordering in global matrix (if possible)

rows()

template<class LocalMatrixTraits >

int Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rows ( ) const

inline

get number of rows within the matrix

scale()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::scale ( const RangeFieldType &  scalar )

inlineinherited

scale matrix with scalar value

Parameters

[in]

scalar

scalar value that scales the matrix

set()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixInterface< LocalMatrixTraits >::set ( const int  localRow, const int  localCol, const RangeFieldType &  value  )

inlineinherited

set value of matrix entry (row,col) where row and col are local row and local column

Parameters

[in]	localRow	local row
[in]	localCol	local column
[in]	value	value to set

unbind()

template<class LocalMatrixTraits >

void Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::unbind ( )

inline

clear local matrix from entities

Member Data Documentation

domainBaseSet_

template<class LocalMatrixTraits >

DomainBasisFunctionSetType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainBaseSet_

protected

domainEntity_

template<class LocalMatrixTraits >

std::optional< DomainEntityType > Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainEntity_

protected

domainSpace_

template<class LocalMatrixTraits >

const DomainSpaceType& Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::domainSpace_

protected

rangeBaseSet_

template<class LocalMatrixTraits >

RangeBasisFunctionSetType Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeBaseSet_

protected

rangeEntity_

template<class LocalMatrixTraits >

std::optional< RangeEntityType > Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeEntity_

protected

rangeSpace_

template<class LocalMatrixTraits >

const RangeSpaceType& Dune::Fem::LocalMatrixDefault< LocalMatrixTraits >::rangeSpace_

protected

---

The documentation for this class was generated from the following file:

• localmatrix.hh
