Dune::BoundarySegment< dim, dimworld, ctype > Struct Template Reference

Base class for classes implementing geometries of boundary segments. More...

#include <dune/grid/common/boundarysegment.hh>

Inheritance diagram for Dune::BoundarySegment< dim, dimworld, ctype >:

Public Types
typedef BoundarySegment< dim, dimworld, ctype >	ThisType
typedef BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > >	BaseType
typedef BaseType::ObjectStreamType	ObjectStreamType

Public Member Functions
virtual	~BoundarySegment ()
	Dummy virtual destructor.
virtual FieldVector< ctype, dimworld >	operator() (const FieldVector< ctype, dim-1 > &local) const =0
	A function mapping local coordinates on a boundary segment to world coordinates.
virtual void	backup (ObjectStreamType &buffer) const
	write BoundarySegment's data to stream buffer

Protected Types
typedef BoundarySegment< dim, dimworld, ctype >	BoundarySegment
	type of BoundarySegment interface class
typedef Dune::ParameterizedObjectFactory< std::unique_ptr< BoundarySegment >(ObjectStreamType &), int >	FactoryType
	type of factory creating a unique_ptr from an ObjectStreamType

Static Protected Member Functions
static std::unique_ptr< BoundarySegment >	restore (ObjectStreamType &in)
	create an object of BoundarySegment type from a previously registered factory linked to key.
static int	registerFactory ()

Detailed Description

template<int dim, int dimworld, class ctype>
struct Dune::BoundarySegment< dim, dimworld, ctype >

Base class for classes implementing geometries of boundary segments.

Some grid implementations, as for example UGGrid, allow to use boundary segments of arbitrary geometry. That means that you can have grid boundaries approach smooth shapes when refining the grid.

Such curved boundary segments are specified by giving classes that implement them. Each boundary segment is implemented by an object of a class derived from BoundarySegment. The set of these objects is handed over to the grid upon grid construction.

Template Parameters

dim	Dimension of the grid
dimworld	Dimension of the Euclidean space the grid is embedded in
ctype	type of coordinate storage (default is double)

Member Typedef Documentation

BaseType

template<int dim, int dimworld, class ctype >

typedef BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > > Dune::BoundarySegment< dim, dimworld, ctype >::BaseType

BoundarySegment

typedef BoundarySegment< dim, dimworld, ctype > Dune::BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > >::BoundarySegment

protectedinherited

type of BoundarySegment interface class

FactoryType

typedef Dune::ParameterizedObjectFactory< std::unique_ptr< BoundarySegment >( ObjectStreamType& ), int > Dune::BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > >::FactoryType

protectedinherited

type of factory creating a unique_ptr from an ObjectStreamType

ObjectStreamType

template<int dim, int dimworld, class ctype >

typedef BaseType::ObjectStreamType Dune::BoundarySegment< dim, dimworld, ctype >::ObjectStreamType

ThisType

template<int dim, int dimworld, class ctype >

typedef BoundarySegment< dim, dimworld, ctype > Dune::BoundarySegment< dim, dimworld, ctype >::ThisType

Constructor & Destructor Documentation

~BoundarySegment()

template<int dim, int dimworld, class ctype >

virtual Dune::BoundarySegment< dim, dimworld, ctype >::~BoundarySegment ( )

inlinevirtual

Dummy virtual destructor.

Member Function Documentation

backup()

template<int dim, int dimworld, class ctype >

virtual void Dune::BoundarySegment< dim, dimworld, ctype >::backup ( ObjectStreamType &  buffer ) const

inlinevirtual

write BoundarySegment's data to stream buffer

Parameters

buffer

buffer to store data

operator()()

template<int dim, int dimworld, class ctype >

virtual FieldVector< ctype, dimworld > Dune::BoundarySegment< dim, dimworld, ctype >::operator() ( const FieldVector< ctype, dim-1 > &  local ) const

pure virtual

A function mapping local coordinates on a boundary segment to world coordinates.

registerFactory()

static int Dune::BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > >::registerFactory ( )

inlinestaticprotectedinherited

restore()

static std::unique_ptr< BoundarySegment > Dune::BoundarySegmentBackupRestore< BoundarySegment< dim, dimworld, ctype > >::restore ( ObjectStreamType &  in )

inlinestaticprotectedinherited

create an object of BoundarySegment type from a previously registered factory linked to key.

Parameters

in	stream buffer previously written with backup containing key and object data

Returns

Object derived from BoundarySegment.

---

The documentation for this struct was generated from the following file:

• boundarysegment.hh
