Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V > Class Template Reference

Gather/scatter communication that passes a single function from each subdomain to all its neighbors. More...

#include <dune/pdelab/backend/istl/geneo/multicommdatahandle.hh>

Public Types
typedef std::size_t	size_type

Public Member Functions
template<typename MessageBuffer , typename Entity , typename LocalView >
bool	gather (MessageBuffer &buff, const Entity &e, LocalView &local_view) const
template<typename MessageBuffer , typename Entity , typename LocalView >
bool	scatter (MessageBuffer &buff, std::size_t n, const Entity &e, LocalView &local_view) const
template<typename MessageBuffer , typename Offsets , typename Entity , typename LocalView >
bool	scatter (MessageBuffer &buff, const Offsets &remote_offsets, const Offsets &local_offsets, const Entity &e, LocalView &local_view) const
	MultiCommGatherScatter (const GFS &gfs, RankIndex rank, std::vector< std::shared_ptr< V > > target_vectors, std::vector< RankIndex > neighbor_ranks)

Detailed Description

template<typename GFS, typename RankIndex, typename V>
class Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >

Gather/scatter communication that passes a single function from each subdomain to all its neighbors.

Member Typedef Documentation

size_type

template<typename GFS , typename RankIndex , typename V >

typedef std::size_t Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >::size_type

Constructor & Destructor Documentation

MultiCommGatherScatter()

template<typename GFS , typename RankIndex , typename V >

Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >::MultiCommGatherScatter ( const GFS &  gfs, RankIndex  rank, std::vector< std::shared_ptr< V > >  target_vectors, std::vector< RankIndex >  neighbor_ranks  )

inline

Parameters

gfs	Grid function space to be operated on.
rank	The MPI rank of the current process.
target_vectors	Vectors which the received vectors will be written to.
neighbor_ranks	List of ranks of neighboring subdomains defining the order in which results are written to target_vectors.

Member Function Documentation

gather()

template<typename GFS , typename RankIndex , typename V >

template<typename MessageBuffer , typename Entity , typename LocalView >

bool Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >::gather ( MessageBuffer &  buff, const Entity &  e, LocalView &  local_view  ) const

inline

scatter() [1/2]

template<typename GFS , typename RankIndex , typename V >

template<typename MessageBuffer , typename Offsets , typename Entity , typename LocalView >

bool Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >::scatter ( MessageBuffer &  buff, const Offsets &  remote_offsets, const Offsets &  local_offsets, const Entity &  e, LocalView &  local_view  ) const

inline

scatter() [2/2]

template<typename GFS , typename RankIndex , typename V >

template<typename MessageBuffer , typename Entity , typename LocalView >

bool Dune::PDELab::MultiCommGatherScatter< GFS, RankIndex, V >::scatter ( MessageBuffer &  buff, std::size_t  n, const Entity &  e, LocalView &  local_view  ) const

inline

---

The documentation for this class was generated from the following file:

• multicommdatahandle.hh
