Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C > Class Template Reference

Iterator over all edges starting from a vertex. More...

#include <dune/istl/paamg/graph.hh>

Public Types
enum	{ isMutable = std::is_same<C, MutableContainer>::value }
typedef std::remove_const< C >::type	MutableContainer
	The mutable type of the container type.
typedef const std::remove_const< C >::type	ConstContainer
	The constant type of the container type.
typedef std::conditional< isMutable &&C::mutableMatrix, typenameMatrix::row_type::Iterator, typenameMatrix::row_type::ConstIterator >::type	ColIterator
	The column iterator of the matrix we use.
typedef std::conditional< isMutable &&C::mutableMatrix, typenameM::block_type, consttypenameM::block_type >::type	Weight
	The matrix block type we use as weights.
typedef std::conditional< std::is_same< C, typenamestd::remove_const< C >::type >::value &&C::mutableMatrix, typenameM::block_type, consttypenameM::block_type >::type	WeightType

Public Member Functions
	EdgeIteratorT (const VertexDescriptor &source, const ColIterator &block, const ColIterator &end, const EdgeDescriptor &edge)
	Constructor.
	EdgeIteratorT (const ColIterator &block)
	Constructor for the end iterator.
template<class C1 >
	EdgeIteratorT (const EdgeIteratorT< C1 > &other)
	Copy Constructor.
WeightType &	weight () const
	Access the edge weight.
EdgeIteratorT< C > &	operator++ ()
	preincrement operator.
bool	operator!= (const EdgeIteratorT< typename std::remove_const< C >::type > &other) const
	Inequality operator.
bool	operator!= (const EdgeIteratorT< const typename std::remove_const< C >::type > &other) const
	Inequality operator.
bool	operator== (const EdgeIteratorT< typename std::remove_const< C >::type > &other) const
	Equality operator.
bool	operator== (const EdgeIteratorT< const typename std::remove_const< C >::type > &other) const
	Equality operator.
VertexDescriptor	target () const
	The index of the target vertex of the current edge.
VertexDescriptor	source () const
	The index of the source vertex of the current edge.
const EdgeDescriptor &	operator* () const
	Get the edge descriptor.
const EdgeDescriptor *	operator-> () const
	Get the edge descriptor.

Friends
class	EdgeIteratorT< MutableContainer >
class	EdgeIteratorT< ConstContainer >

Detailed Description

template<class M>
template<class C>
class Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >

Iterator over all edges starting from a vertex.

Member Typedef Documentation

ColIterator

template<class M >

template<class C >

typedef std::conditional<isMutable&&C::mutableMatrix,typenameMatrix::row_type::Iterator,typenameMatrix::row_type::ConstIterator>::type Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::ColIterator

The column iterator of the matrix we use.

ConstContainer

template<class M >

template<class C >

typedef const std::remove_const<C>::type Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::ConstContainer

The constant type of the container type.

MutableContainer

template<class M >

template<class C >

typedef std::remove_const<C>::type Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::MutableContainer

The mutable type of the container type.

Weight

template<class M >

template<class C >

typedef std::conditional<isMutable&&C::mutableMatrix,typenameM::block_type,consttypenameM::block_type>::type Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::Weight

The matrix block type we use as weights.

WeightType

template<class M >

template<class C >

typedef std::conditional<std::is_same<C,typenamestd::remove_const<C>::type>::value&&C::mutableMatrix,typenameM::block_type,consttypenameM::block_type>::type Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::WeightType

Member Enumeration Documentation

anonymous enum

template<class M >

template<class C >

anonymous enum

Enumerator
isMutable	whether C is mutable.

Constructor & Destructor Documentation

EdgeIteratorT() [1/3]

template<class M >

template<class C >

Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::EdgeIteratorT	(	const VertexDescriptor &	source,
		const ColIterator &	block,
		const ColIterator &	end,
		const EdgeDescriptor &	edge
	)

Constructor.

Parameters

source	The source vertex of the edges.
block	The matrix column block the iterator is initialized to,
end	The end iterator of the matrix row.
edge	The edge descriptor of the current edge.

EdgeIteratorT() [2/3]

template<class M >

template<class C >

Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::EdgeIteratorT

(

const ColIterator &

block

)

Constructor for the end iterator.

Variables not needed by operator== or operator!= will not be initialized.

Parameters

block

The matrix column block the iterator is initialized to.

EdgeIteratorT() [3/3]

template<class M >

template<class C >

template<class C1 >

Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::EdgeIteratorT

(

const EdgeIteratorT< C1 > &

other

)

Copy Constructor.

Parameters

other

The iterator to copy.

Member Function Documentation

operator!=() [1/2]

template<class M >

template<class C >

bool Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator!=

(

const EdgeIteratorT< const typename std::remove_const< C >::type > &

other

)

const

Inequality operator.

operator!=() [2/2]

template<class M >

template<class C >

bool Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator!=

(

const EdgeIteratorT< typename std::remove_const< C >::type > &

other

)

const

Inequality operator.

operator*()

template<class M >

template<class C >

const EdgeDescriptor & Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator*

(

)

const

Get the edge descriptor.

operator++()

template<class M >

template<class C >

EdgeIteratorT< C > & Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator++

(

)

preincrement operator.

operator->()

template<class M >

template<class C >

const EdgeDescriptor * Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator->

(

)

const

Get the edge descriptor.

operator==() [1/2]

template<class M >

template<class C >

bool Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator==

(

const EdgeIteratorT< const typename std::remove_const< C >::type > &

other

)

const

Equality operator.

operator==() [2/2]

template<class M >

template<class C >

bool Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::operator==

(

const EdgeIteratorT< typename std::remove_const< C >::type > &

other

)

const

Equality operator.

source()

template<class M >

template<class C >

VertexDescriptor Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::source

(

)

const

The index of the source vertex of the current edge.

target()

template<class M >

template<class C >

VertexDescriptor Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::target

(

)

const

The index of the target vertex of the current edge.

weight()

template<class M >

template<class C >

WeightType & Dune::Amg::MatrixGraph< M >::EdgeIteratorT< C >::weight

(

)

const

Access the edge weight.

Friends And Related Symbol Documentation

EdgeIteratorT< ConstContainer >

template<class M >

template<class C >

friend class EdgeIteratorT< ConstContainer >

friend

EdgeIteratorT< MutableContainer >

template<class M >

template<class C >

friend class EdgeIteratorT< MutableContainer >

friend

---

The documentation for this class was generated from the following file:

• graph.hh
